Pramac LTS 400A Automatic Transfer Switch for DIESEL / GAS
Contact Us About this Product
Pramac LTS 400A three phase automatic transfer switch (ATS) for seamless mains-to-generator changeover for DIESEL / GAS. 400A rated, motorized 4-pole, 208-480V 50/60Hz, ideal for large commercial, heavy industrial & critical backup systems.
SAFE & SECURE CHECKOUT
Description
Pramac LTS 400A Automatic Transfer Switch for DIESEL / GAS
The Pramac LTS 400A Automatic Transfer Switch (ATS) automatically takes over when mains power fails, quickly detecting the outage, starting your backup generator (via ACP connection), and switching your load over smoothly — usually in seconds — to keep everything running without missing a beat.
When the grid comes back online and is stable, it safely returns power to mains and shuts down the generator. This motorized 4-pole model is designed specifically for 400V three-phase systems and provides reliable, high-capacity performance for medium to large commercial premises, industrial facilities, workshops, farms, offices, or heavy-duty backup applications. The panel-mounted design with high-quality motorized changeover switch ensures easy integration, and it’s engineered to work seamlessly with Pramac generators equipped with ACP/AMF controls.
Set it up once and forget it — dependable automatic backup switching when you need it most.
Key Features:
- Automatic Motorized Changeover → Senses mains failure, starts generator, transfers load fast
- 400A Capacity (4 Pole) → Supports very high three-phase loads with switched neutral
- Wide Voltage & Frequency → 208-480V, 50/60Hz for flexible use
- Quick & Safe Transfer → Minimizes downtime during blackouts
- Monitoring & Protection → Over/under voltage, phase failure safeguards
- Durable Enclosure → Weather-resistant for indoor/outdoor install (wall or panel mount)
- Pramac Compatibility → Works seamlessly with ACP/AMF gensets
Whether you’re protecting your home, workshop, or business from blackouts with seamless generator switchover, the Pramac 400A Load Transfer Switch Panel delivers reliable, hands-free power protection. Shop now at No More Blackouts for quality you can trust.
Please visit our store for more Home, Industrial and Portable Generator options.
Product Specifications
- Phase : Three phase (4 Pole – switched neutral)
- Rated Current : 400A
- Voltage Range : 208-480V
- Frequency : 50/60 Hz
- Transfer Type : Automatic motorized (open transition)
- Monitoring : Mains voltage/frequency, phase failure, over/under voltage
- Transfer Time : Seconds (typical)
- Enclosure : Wall-mount, weather-resistant (IP-rated)
- Dimensions : Approx. 90 cm H x 70 cm W x 35 cm D
- Weight : Approx. 65 kg
- Compatibility : Pramac gensets with ACP/AMF control
- Protection : Overload, short-circuit, emergency stop
- Configuration : Motorized changeover, standard accessories
Download Specifications Sheet
